Skirtboard rubber is made of SBR or Natural Rubber, and is available in a wide variety of gauges and widths. It is common to every conveyor application and paramount in the prevention of spillage at material loading points. It is a specifically designed rubber sheet used as sealing strip on conveyor system loading, transfer and discharge points.
Abrasion and Weather Resistant
Shore Hardness: 40° ± 5°/ 60° ± 5°/ 65° ± 5°
Temperature: -20°C up to +80°C (+90 °C intermittent).
500 PSI and 650 PSI Tensile Strength, 300 % Elongation
Cut Widths (Not Extruded)
Use with conveyor belt or as chute lining, mining plants, cement
SKIRTBOARD RUBBER | |||||
SPECIFICATION | HARDNESS SHOREA |
S.G. G/CM3 |
TENSILE STRENGTH MPA |
ELONGATION AT BREAK % |
COLOUR |
Economy Grade | 65 | 1.50 | 3.0 | 200 | Black |
Soft SBR | 50 | 1.35 | 4.0 | 250 | Black |
Commercial Grade | 60 | 1.30 | 4.2 | 250 | Black |
High Grade | 40 | 1.05 | 18.00 | 600 | Black |
Standard Width | 2″ 3″ 4″ 5″ 6″7″8″10″ 12″ 48″ |
Standard Length | 50′ |
Standard Thickness | 1/4″ 3/8″ 1/2″ 3/4″ 1″ |
Custom sizes available upon request.
