Specifically designed to provide strong resistance against objects that might rip through the belt, impact-resistant conveyor belts are used for carrying jagged materials in heavy-duty conditions, especially where large drop heights are involved. Impact-resistant belts operate effectively in this environment due to a special textile or metal weave, known as a breaker.The rubber covers are equipped to handle the impact, minimise rips and tears, resist aggressive wear and reduce gouging and cutting caused by hard, sharp materials.
Impact resistant conveyor belts are recommended for carrying lumpy, jagged materials in heavy duty conditions. These types of conveyor belts feature high impact and tear resistance provided by a special textile or metal weave called a breaker. The type of breaker used to manufacture rip and impact resistant conveyor belts differs depending on the application. For increasing lateral strength, high elongation steel mesh is used as weft cord. For increasing lateral stiffness, regular steel mesh can be used. Breaker material is also available as a fabric weave with increased tear and impact resistance for lighter working conditions where steel is not required.
Excellent resistance to cuts and abrasion
Long-lasting impact resistance with minimal belt damage
Excellent resistance to sandwiching
Standard and made-to-order products are available
China GB/T7984 Standard
Germany DIN22102 Standard
US RMA Standard
UK EN ISO15236 Standard
Japan JISK6322 Standard
Australia AS1332 Standard
| STEADFAST STANDARD | DIN QUALITY | TENSILE STRENGTH | ELONGATION AT BREAK | ABRASION LOSS | BASE POLYMER | TECHNICAL FEATURES APPLICATION AREA |
| Abrasion resistant | DIN W | 180 | 400 | 90 | NR/ SBR | Abrasion resistant covers provide a very high level of abrasion and cut and tear resistant. These kinds of rubber covers also feature good weather resistance. |
| DIN X | 250 | 450 | 120 | NR/ SBR | Abrasion resistant covers provide a very high level of abrasion and cut and tear resistant. These kinds of rubber covers also feature good weather resistance. |
|
| DIN Y | 200 | 400 | 150 | SBR | Used for general use applications with superior resistance to abrasion, weather and cuts. |
