Large Angle Sidewall Conveyor Belt

Product Classification

A large angle sidewall conveyor belt is a conveyor belt that is designed with high-angle cleats or corrugated sidewalls that enable it to handle materials at steep inclines, even up to 90 degrees. The belt is usually made of durable rubber or PVC material and is ideal for transporting bulk materials such as coal, sand, grain, and other materials from one location to another. The design of the belt prevents the material from slipping or spilling during transportation, making it an effective solution for industries such as mining, agriculture, and construction.

Require Now

Product Use

  1. Mining and Minerals: Large angle sidewall conveyor belts are used to transport raw materials such as coal, ores, and other minerals from mines to processing plants.
  2. Agriculture: The belt can be used to transport crops, seeds, and fertilizers from one location to another, including up steep inclines.
  3. Construction: The belt is used to transport construction materials such as sand, gravel, and concrete over inclined surfaces and around corners.
  4. Cement and Concrete: Large angle sidewall conveyor belts can be used to transport cement and concrete over long distances and up steep inclines.
  5. Waste Management: The belt is used in waste management facilities to transport various types of waste material, including household waste, construction waste, and hazardous waste.

Product Structure

Product Features

  1. High Angle Cleats: The belt is designed with high angle cleats or ribs that provide a positive and safe movement of material at steep inclines.
  2. Corrugated Sidewalls: The sidewalls of the belt are corrugated, which creates a pocket that surrounds the material being transported.
  3. Durable Materials: The belt is made of high-quality rubber or PVC materials which can withstand the harsh working environment, abrasion, and other forms of wear and tear.
  4. Strong Tensile Strength: The belt has strong tensile strength, which means it can withstand the high stress of conveying heavy materials over long distances.
  5. Customizable: The belt can be customized to fit the specific requirements of the application.

Executive Standard

China GB/T7984 Standard

Germany DIN22102 Standard

US RMA Standard

UK EN ISO15236 Standard

Japan JISK6322 Standard

Australia AS1332 Standard

Main Technical Parameters

Base Belt Width B(mm) Sidewall Height H(mm) Cleat Height H1(mm) Bf(mm) Br(mm) R(mm)
300 40 35 25 180 35
60 55 50 120 40
80 75
400 60 55 50 180 60
80 75
100 90
500 80 75 50 250 75
100 90
120 110
650 100 90 50 350 100
120 110
160 140 75 300
800 120 110 50 460 120
160 140 75 410
200 180
1000 160 140 75 550 150
200 180
240 220
1200 160 140 75 690 180
200 180
240 220
300 280 105 630
1400 200 180 75 830 210
240 220
300 280 105 770
400 360
1600 200 180 75 970 240
240 220
300 280 105 910
400 360
1800 240 220 75 1110 270
300 280 105 1050
400 360
500 460 125 1010
