Conveyor Belts With Metal Breakers

Product Classification

According to the cover property, it can be divided into the following types: general type, tear resistant type, heat resistant type, fire retardant type, cold resistant type, oil resistant type, acid-alkali resistant type, etc.

Require Now

Product Use

Conveyor Belts with metal breakers are widely used in material delivery for cement plants, coal/coke, stone quarries, mine, electric power, and the chemical industry.

Product Structure

The conveyor belts be equipped with a metal breaker ply whose function is to protect the belt from ripping or impact. It is also possible to have two or more breaker plies if the condition is more extreme.

Product Features

Excellent impact resistance

High tensile strength

Lesser elongation in use

Good resistance to edge wear

Suitable for conveying material over long distances

Executive Standard

US RMA Standard

UK EN ISO15236 Standard

China GB/T7984 Standard

Germany DIN22102 Standard

Japan JISK6322 Standard

Australia AS1332 Standard

Main Technical Parameters

Characteristics of insertions Insertions number 2 – 4
Type of insertion EP 80 EP  100 EP 125 EP

160

 EP

200

 EP

250

 EP

315

 EP

400
Tensile strength, kgf, (for 50mm * 200mm  ) longitudinal 500 700 800 1000 1200 1500 2000 2200
transversal 250 250 350 380 500 500 500 500





Breaker characteristics Type of breaker BF 125 RE BF 125 HE
Transverse strength range, N/mm 125 125
Mass, kg/m2 0.55 0.75
Density, yarns/m 200 200
Warp strength, N/mm 50 50
WEFT CORDS 2 * 2 * 0.38 4 * 4 * 0.22
Diameter, mm 1.00 1.35
Breaking load Average, N 1050 1220
Minimum, N 970 1150
Pitch, mm 7.5 8.9
Density, cord/m 133 112



Video

Company Introduction

FAQ

Q1. How about your experience?

We have mainly produced rubber conveyor belts for over 20 years.

Q2. What are your main products?

Multi-ply fabric conveyor belt(EP/NN type), steel cord conveyor belt, chevron conveyor belt, sidewall belt, white conveyor belt, bucket elevator belt, filter belt, and special conveyor belts with the characteristics of heat resistant, cold resistant, oil resistant, flame retardant, abrasion resistant, etc.

Q3. What about the lead time?

1) 3--5 days for sample.
2) 20--25 days for mass production. If urgent, we have the green channel.

Q4. Can you send free samples?

Yes, we provide samples for free after inquiry.

Q5. How about the package?

Standard export packing method, your special requirement will be respected.

Q6. What are your Payment terms?

T/T or L/C.

Q7. Can you do door-to-door?

No problem.

Q8. How do you ensure your product quality?

Our quality control system had been ISO9001 certified. The first-class production equipment, testing facilities, and a complete quality assurance system guarantee high quality.

Q9. What is your major market?

Our products are heavily involved in exporting all over the world, including Europe, America, the Middle East, Southeast Asia, South Africa, Australia, etc.

Q10. What you can do to support me better?

We can provide products that meet quality standards, timely delivery, transportation packaging requirements, and customers' other special requirements.
