Conveyor Belts for Mining Industry

Product Classification

Conveyor belts for mining industry are used to transport heavy materials, such as rocks, ore, and gravel, from one place to another. These conveyor belts are typically made of durable materials like rubber or steel and consist of one or more layers of fabric that are reinforced with steel cords or other reinforcement materials to increase their strength and durability.

Require Now

Product Use

Mining conveyor belts can be very long and cover large distances, sometimes spanning several kilometers. They are often used to transport the extracted materials from the mine to the processing plant or transportation hub. In addition to their primary function of material transportation, mining conveyor belts may also be used for other purposes, such as controlling the speed and flow of material or as a safety mechanism to prevent oversize materials from causing blockages or other problems. Overall, conveyor belts are an essential component of many mining operations, as they help to improve efficiency, lower operating costs, and increase worker safety while transporting large quantities of heavy materials over long distances.

Product Structure

Product Features

  1. Durability: Mining conveyor belts are made of durable materials, such as rubber or steel, that can withstand the harsh conditions of mining operations, including abrasion, corrosion, and extreme temperatures.
  2. Strength: These conveyor belts are reinforced with steel cords or other reinforcement materials, which provides them with the strength needed to carry heavy loads over long distances.
  3. Flexibility: Mining conveyor belts are designed to be flexible and adaptable to changing terrain and obstacles, making them ideal for use in mines with varying layouts or underground mines.
  4. Safety: Conveyor belts used in the mining industry often come equipped with safety features, such as fire-resistant materials, emergency stop buttons, and automatic shutoff systems.
  5. Efficiency: Conveyor belts make material transport more efficient by reducing the need for manual labor, increasing throughput, and reducing downtime.

Executive Standard

China GB/T7984 Standard

Germany DIN22102 Standard

US RMA Standard

UK EN ISO15236 Standard

Japan JISK6322 Standard

Australia AS1332 Standard

Main Technical Parameters

strength of the belt specifications ST
630		 ST
800		 ST
1000		 ST
1250		 ST
1600		 ST
2000		 ST
2500		 ST
3150		 ST
3500		 ST
4000		 ST
4500		 ST
5000		 ST
5400		 ST
6300
longitudinal tensible strength 630 800 1000 1250 1600 2000 2500 3150 3500 4000 4500 5000 5400 6300
Maximal nominal diameter
of the steel wire mm		 3.0 3.5 4.0 4.5 5.0 6.0 7.2 8.1 8.6 8.9/9.1 9.7 10.9 11.3 12.3
Space between cord 10 10 12 12 12 12 15 15 15 15/17 16 17 17 18
Top cover thickness 5 5 6 6 6 8 8 8 8 8/8 8 8.5 9 10
Bottom cover thickness 5 5 6 6 6 6 6 8 8 8/8 8 8.5 9 10
Quality 18 19.5 21.5 22.2 26.1 33.1 35.3 41.1 45 45/45 51 59 62 65



Video

Company Introduction

FAQ

Q1. How about your experience?

We have mainly produced rubber conveyor belts for over 20 years.

Q2. What are your main products?

Multi-ply fabric conveyor belt(EP/NN type), steel cord conveyor belt, chevron conveyor belt, sidewall belt, white conveyor belt, bucket elevator belt, filter belt, and special conveyor belts with the characteristics of heat resistant, cold resistant, oil resistant, flame retardant, abrasion resistant, etc.

Q3. What about the lead time?

1) 3--5 days for sample.
2) 20--25 days for mass production. If urgent, we have the green channel.

Q4. Can you send free samples?

Yes, we provide samples for free after inquiry.

Q5. How about the package?

Standard export packing method, your special requirement will be respected.

Q6. What are your Payment terms?

T/T or L/C.

Q7. Can you do door-to-door?

No problem.

Q8. How do you ensure your product quality?

Our quality control system had been ISO9001 certified. The first-class production equipment, testing facilities, and a complete quality assurance system guarantee high quality.

Q9. What is your major market?

Our products are heavily involved in exporting all over the world, including Europe, America, the Middle East, Southeast Asia, South Africa, Australia, etc.

Q10. What you can do to support me better?

We can provide products that meet quality standards, timely delivery, transportation packaging requirements, and customers' other special requirements.
