Cold resistant conveyor belt is mainly used for conveying materials in cold areas, such as open air or refrigerated warehouses under -60℃~+50℃.
The cold resistant conveyor belt is made of multi-ply rubberized nylon canvas and EP canvas as the skeleton material, covered with cold resistant coating rubber, and made by calendering, molding, curing and other processes.
This product has the characteristics of cold resistance, high elasticity, impact resistance, wear resistance, etc. it can be used normally under – 60 ℃.
| Item | Type | ||||
| NN、EP | |||||
| Adhesion strength | Between coating and belt cores | Thickness of coating＞1.5mm ≥ N/mm | 3.5 | ||
| Thickness of coating 0.8~1.5mm ≥ N/mm | 3.2 | ||||
| Between layers ≥ N/mm | 4.5 | ||||
| Longitudinal full thickness tensile strength value of belt/ N/mm | 160～3150 | ||||
| Longitudinal elongation at break of full thickness of belt/ %≥ | 10 | ||||
| Elongation of longitudinal reference force of full thickness belt/ %≤ | 4 | ||||
| Coating performance | H | D | L | ||
| Breaking strength/ MPa≥ | 24 | 18 | 15 | ||
| Elongation at break /%≥ | 450 | 400 | 350 | ||
| (70 ℃× 7D)Aging test (70 ℃× 7D)
Change rate of tensile strength / % Change rate of elongation at break / % |
±25 | ||||
| Abrasion/ mm3≤ | 120 | 100 | 200 | ||
| Tensile cold resistance coefficient
≤ |
C1 (- 45 ℃) applicable environment temperature – 45 ℃ ~ + 50 ℃ | 0.3 | |||
| C2 (- 50 ℃) applicable environment temperature – 60 ℃ ~ + 50 ℃ | 0.2 | ||||
