Closed Cotton Conveyor Belt

Product Classification

According to whether there is edge rubber: Molded edge belt and Cut edge belt.

According to their cover rubber types: Heat-resistant, Oil-resistant, Flame-resistant, and Anti-static, among others. The appropriate cover rubber type is selected based on the specific application requirements.

Require Now

Product Use

This Closed cotton conveyor belt is commonly used in industries such as agriculture, food processing, and manufacturing for handling bulk materials, including grains, flour, sugar, and other dry and powdery substances.

Product Structure

Closed cotton conveyor belt is a conveyor belt that has a closed loop design with no openings or gaps between the edges of the belt. Closed cotton conveyor belts are typically made of multiple layers of cotton canvas material that are tightly woven together to form a strong and durable belt. The layers are usually coated with a rubber or plastic material that provides additional strength, resistance to abrasion and chemicals, and helps to prevent moisture absorption.

Product Features

  1. Reduced product contamination: The closed loop design of the conveyor belt prevents materials from falling off, reducing the risk of product contamination.
  2. Improved safety: The closed design also reduces the risk of accidents and injuries to workers by preventing them from getting caught in between the belt edges.
  3. Better product protection: The closed cotton conveyor belt protects products from external factors such as moisture or dust, which can affect the quality of the materials being transported.
  4. Increased efficiency: Closed cotton conveyor belts can transport materials more efficiently with minimal spillage, allowing for greater productivity and a faster production process.
  5. Environmentally friendly: As mentioned earlier, cotton material used in manufacturing a closed cotton conveyor belt is environmentally friendly and biodegradable, making them sustainable and a good option for businesses that prioritize sustainability.

Executive Standard

DIN22102, RMA, AS1332, SABS 1173/2000, IS 1891, BS490, JIS K 6322, etc.

Main Technical Parameters

Type Textile type Strength per ply
Min.(N/mm)		 Plies of fabric Cover thickness(mm) Belt width
(mm)		 Cover grade
Top cover Bottom cover

EP belt

 EP-100 100

2-8

 2-16 0-10 300-3400 Abrasion resistant
Impact resistant
Heat resistant
Oil resistant
Acid/alkali resistant
Fire resistant
Etc.
EP-125 125
EP-150 150
EP-200 200
EP-250 250
EP-300 300
EP-350 350
EP-400 400
EP-500 500

NN belt

 NN-100 100

2-10
NN-125 125
NN-150 150
NN-200 200
NN-250 250
NN-300 300
NN-400 400
NN-500 500
CC belt CC56 56 3-12



Video

Company Introduction

FAQ

Q1. How about your experience?

We have mainly produced rubber conveyor belts for over 20 years.

Q2. What are your main products?

Multi-ply fabric conveyor belt(EP/NN type), steel cord conveyor belt, chevron conveyor belt, sidewall belt, white conveyor belt, bucket elevator belt, filter belt, and special conveyor belts with the characteristics of heat resistant, cold resistant, oil resistant, flame retardant, abrasion resistant, etc.

Q3. What about the lead time?

1) 3--5 days for sample.
2) 20--25 days for mass production. If urgent, we have the green channel.

Q4. Can you send free samples?

Yes, we provide samples for free after inquiry.

Q5. How about the package?

Standard export packing method, your special requirement will be respected.

Q6. What are your Payment terms?

T/T or L/C.

Q7. Can you do door-to-door?

No problem.

Q8. How do you ensure your product quality?

Our quality control system had been ISO9001 certified. The first-class production equipment, testing facilities, and a complete quality assurance system guarantee high quality.

Q9. What is your major market?

Our products are heavily involved in exporting all over the world, including Europe, America, the Middle East, Southeast Asia, South Africa, Australia, etc.

Q10. What you can do to support me better?

We can provide products that meet quality standards, timely delivery, transportation packaging requirements, and customers' other special requirements.
